2002 Lincoln LS Owners Manual

Introduction 4 Congratulations 4 Safety and environment protection 5 Symbol glossary 8 Instrument Cluster 10 Warning and control lights 10 Gauges 16 Entertainment Systems 19 AM/FM stereo cassette 19 AM/FM stereo with CD 31 CD changer 44 Climate Controls 48 Electronic automatic temperature control 48 Lights 60 Headlamps 60 Bulb replacement 65 Driver Controls 69 Steering wheel adjustment 72 Power windows 73 Mirrors 77 Message center 94 Locks and Security 108 Keys 108 Locks 108 Anti-theft system 111 Table of Contents 1

Seating and Safety Restraints 121 Seating 121 Safety restraints 126 Air bags 139 Child restraints 146 Driving 156 Starting 156 Brakes 160 Traction control/AdvanceTrac 164 Transmission operation 167 Vehicle loading 181 Trailer towing 183 Recreational towing 186 Roadside Emergencies 187 Hazard flasher switch 188 Fuses and relays 190 Changing tires 198 Jump starting 202 Wrecker towing 209 Customer Assistance 210 The dispute settlement board 213 Utilizing the mediation/arbitration 216 Getting assistance outside the U.S. and Canada 216 Ordering additional owner’s literature 217 Reporting safety defects (U.S. only) 219 Table of Contents 2

Cleaning 220 Cleaning your vehicle 220 Underbody preservation 226 Maintenance and Specifications 228 Hood 229 Engine compartment 230 Engine oil 232 Battery 235 Fuel information 245 Air filter(s) 253 Part numbers 261 Refill capacities 261 Lubricant specifications 263 Engine data 264 Vehicle dimensions 270 Accessories 273 Index 276 All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2001 Ford Motor Company Table of Contents 3

The following warning may be required by California law: CALIFORNIA Proposition 65 Warning WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: In the United States: www.ford.com In Canada: www.ford.ca In Mexico: www.ford.com.mx In Australia: www.ford.com.au Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on the Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle. Introduction 4

Fuel pump shut-off switch In the event of an accident the safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside emergencies chapter. SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed. Warning symbols on your vehicle When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind. Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol. Introduction 5

BREAKING-IN YOUR VEHICLE There are no particular guidelines for breaking-in your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is recommended to give the moving parts a chance to break in. SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide. Special instructions For your safety, your vehicle is fitted with sophisticated electronic controls. By operating other electronic equipment (e.g. mobile telephone without exterior aerial) electromagnetic fields can occur which can cause malfunctions of the vehicle electronics. Therefore you should observe the instructions of the equipment manufacturers. Please read the section Air bag in the Seating and safety restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury. Rear facing child or baby seats should NEVER be used in front of a passenger side air bag. Introduction 6

MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this Owner Guide for all other required information and warnings. Introduction 7

These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Warning Child Seat Tether Anchorage Brake System Anti-Lock Brake System Brake Fluid - Non-Petroleum Based Traction Control Master Lighting Switch Hazard Warning Flasher Fog Lamps-Front Fuse Compartment Fuel Pump Reset Windshield Wash/Wipe Windshield Defrost/Demist Rear Window Defrost/Demist Power Windows Front/Rear Power Window Lockout Introduction 8

Vehicle Symbol Glossary Child Safety Door Lock/Unlock Interior Luggage Compartment Release Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, or Sparks Battery Acid Explosive Gas Fan Warning Power Steering Fluid Maintain Correct Fluid Level MAX MIN Emission System Engine Air Filter Passenger Compartment Air Filter Jack Check fuel cap Low tire warning Introduction 9

WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, have the respective system inspected immediately. Check engine Illuminates briefly to ensure the system is functional. If it comes on after the engine is started, one of the engine’s emission control systems may be malfunctioning. The light may illuminate without a driveability concern being noted and will not require towing. Light turns on solid: Temporary malfunctions may cause your light to illuminate. Examples are: • The vehicle has run out of fuel. • Poor fuel quality or water in the fuel. • The fuel cap may not have been properly installed and securely tightened. These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the fuel cap. After three driving cycles without these or any other temporary malfunctions present, the light should turn off. (A driving cycle consists of a cold engine startup followed by mixed city/highway driving.) No additional vehicle service is required. 0 0 20 40 60 80 100 120 140 160 1 2 3 4 5 6 7 P ! BRAKE H C 40 80 120 160 200 240 km/h RPMX1000 RESET MPH A/B F E CHECK FUEL CAP TRIP kmiles A B D 5 Instrument Cluster 10
